Top type stapling head uses SWC7437 3/4" 4M staples

×



These are special-order items, 7 day availability.  Please call to order.

The Salco AD-series of pneumatic stapling heads are a lower cost option for installation in automated corrugated box building machines.  Available in top and bottom stapling versions, they use SWC [Bostitch-type] 4M roll staples, in either 5/8” [15mm] or 3/4” [18mm] leg lengths.  Based on our proven RF-series of roll-feed top carton staplers, the AD head is a reliable, high-speed stapling solution for automated continuous corrugated carton-building and/or closing machines.

Features:
  • Can operate continuously
  • Staple-depth penetration is adjustable from 0-1/4” [0-5mm]
  • Engineered for high-speed operation
  • Automatic stop at end of staple load
  • Ideal for replacing or augmenting automated glue or taping closure for additional security and integrity of corrugated box closure is desired
  • Lowest priced automated roll-feed stapling head available

  Top Stapling Heads Schematics (pdf)

Item: ADT-S-18
